Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction machinery. They produce machines like manlifts, boom lifts and aerial lifts. These machines are designed to facilitate access to difficult to reach areas, large equipment, buildings and roofs, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt moves only in one direction and contains platforms, or steps or handholds that are attached to the unit in order to move employees from each floor.
TB85
The Terex TB85 provides a maximum working height of 91 feet. Furthermore, the maximum height of the platform reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model provides a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal measuring 75 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is about 8.5 feet wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, whilst the max working height measures at 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
